ANUTRON-1513 Polyacetal (POM) is a highly crystalline thermoplastic, with a high mechanical strength and rigidity. ANUTRON-1513 has a low coefficient of friction, excellent wear resistance and low moisture absorption. ANUTRON-1513 has good sliding characteristics making it useful in applications like gear, gear-racks, rollers, bearing blocks, wear plates, bushing, slipper pads, sliding bars, pulleys, etc.
The high dimension stability and easy machinability, compared to metals, it makes it highly versatile engineering plastic. It is a good and cost-effective replacement to ferrous and non-ferrous metals. Being very light weight compared to metals, it makes it easier to handle large components during maintenance.
| Property | Unit | Test Method | Value |
|---|---|---|---|
| Specific Gravity | gm/cc | ASTM D 792 | 1.41 |
| Tensile strength at Yield | Kgf/cm² | ASTM D 638 | 668 |
| Flexural Strength | Kgf/cm² | ASTM D 790 | 840 |
| Flexural Modulus | Kgf/cm² | ASTM D 790 | 28,120 |
| Impact strength (Izod Notch) at 23 C | Ftlbs/in | ASTM D 256 | 10 |
| Rockwell Hardness | R Scale | ASTM D 785 | 120 |
| Softening Point Vicat | °C | ASTM D 1525 | 140 |
| Melting Point | °C | ASTM D 3418 | 168 |
| Maximum service temperature | |||
| Continuous | °C | 82 | |
| Intermittent | °C | 110 | |
| Co-efficient of Linear Expantion | In/in°C | ASTM D 696 | 5.4 |
| Flammability | UL-94 | HB |
Anuman Engineering Industries is an emerging manufacturing unit in the field of Engineering Plastic with a vast experience of over six-decade in the Engineering Plastic business.
