ANUTRON-0813 High Molecular-weight Polyethylene (HMWPE) has has good abrision and impact resistance properties. ANUTRON-0813 has a major advantages in toughness, abrasion resistance and freedom from stress cracking. ANUTRON-0813 shares the lubricity, chemical resistance and excellent electrical properties of conventional HDPE. ANUTRON-0813 has several properties, particularly abrasion resistance (two times better than carbon steel) and suitable for extremely low temperature applications (-100 C to 80 C); . In the food processing industry, its self lubricating properties and resistance to boiling water are exploited. It complies with FDA requirements for handling food, water and pharmaceuticals. Many uses are based on its noise and shock absorbing properties. In mining industry, ANUTRON-0813 is used as liners in chutes and hoppers due to its good abrasion and chemical resistance.
Conveying of bulk materials via chutes, toughs, hoppers and similar devices are often disrupted by cracking, bridging or freezing. These disruptions neutralise the advantages which are achieved by mechanical or automatic charging and conveyance of bulk materials. Interruption of materials flow can cause a lot of problems and expenses. These problems can be solved by using ANUTRON-0813 Linings
The anti stick paraffin like slippery surface of ANUTRON-0813 has a very low coefficient of friction which makes it an ideal material for lines when handling cohesive bulk solids. This surface characteristic has a tendency to promote smooth flow of materials rather than obstruct it. Its zero moisture absorption reduces the problem of bulk solid freezing on its surface.
Due to extremely high molecular weight ANUTRON-0813 has excellent wear resistance properties including high impact strength, breaking strength and high abrasion resistance values
| Property | Unit | Test Method | Value |
|---|---|---|---|
| Density | g/cm³ | ASTM D792 | 0.96 |
| Water Absorption | % | ASTM D570 | <0.01 |
| Flammability (3mm/6mm Thick) | UL 94 | HB | |
| Yield Stress | Kgf/cm² | ASTM D638 | 150 |
| Elongation at Break | % | ASTM D638 | ˃180 |
| Tensile Module of Elestasity | kgf/cm² | ASTM D638 | 6000 |
| Notched Inpact Strength(Charpy) | KJ/m² | ASTM D 256 | 60 |
| Shore Hardness | D Scale | ASTM D2240 | 63 |
| Wear Resistance | Sand-slurry | 45 | |
| Melting Temperature | °C | ASTM D3418 | 5 |
| Working Temperature (continous) | °C | ASTM D3418 | (-100 to 80) |
| Working Temperature (short term) | °C | ASTM D3418 | 110 |
| Heat Deflection Temperature | °C | ASTM D 648 | 75 |
| Thermal Condictivity | W/ (m*K) | 0.40 | |
| Thermal Capacity | kj/(kg*K) | 1.90 | |
| Coefficient of Linear Thermal Expansion | 10¯⁶Kˉ¹ | 150 - 230 |
| ANUTRON-0813 | 28 | PHOSPHER BRONZE | 190 |
| NYLON | 31 | PHENOLIC LAMINATE | 304 |
| PTFE | 72 | L.E. | 200 |
| SS | 84 | YELLOW BRASS | 400 |
| HDPE | 86 | LDPE | 530 |
| POLYCARBONATE | 96 | HARD NEOPRENE RUBBER | 800 |
| CARBON STEEL | 100 | HICKERY WOOD | 950 |
